WDubhe Full HD Endoscopic System

Details

The camera head connects to the endoscope via the optical coupler and converts the optical image into an electrical signal. The image processing unit receives the signal and performs image processing such as image staining, structural enhancement, and noise reduction.

Category

Full HD Endoscopic System

Share to

Send Inquiry

1.Connected to an optical endoscope, the system converts and processes the image captured by the endoscope and transmits it to a monitor for display.

2.It enables physicians or qualified medical personnel to observe lesions during diagnostic or therapeutic endoscopic procedures, supporting clinical decision-making. The system also supports image capture and video recording/storage for post-operative review, documentation, and information sharing.

▼The camera head connects to the endoscope via the optical coupler and converts the optical image into an electrical signal. The image processing unit receives the signal and performs image processing such as image staining, structural enhancement, and noise reduction. The processed image is then output to the monitor via interfaces such as 3G-SDI or HDMI. For certain models, selected functions can be synchronized or controlled through a LINK cable, enabling system integration with devices such as a cold light source or insufflator.

01/

Intended Use Environment:

Applicable for various endoscopic diagnostic and therapeutic procedures.
The system can also be used in cardiovascular-related procedures when operated together with medical electrical equipment that meets CF (Cardiac Floating) safety requirements.

02/

Environmental Conditions:

The device shall be operated in an environment with:
Ambient temperature: 5℃ to 40℃
Relative humidity: ≤ 80% (non-condensing)
Atmospheric pressure: 700 hPa to 1060 hPa
Operation in oxygen-enriched environments or in the presence of flammable anesthetic gases or explosive mixtures is strictly prohibited.
