01/

Systematic Working Modes

Two working modes:

ABLATE for cutting and ablation activated at Yellow control panel and Yellow foot pedal.

COAG for coagulation and hemostasis activated at Blue control panel and Blue foot pedal.

02/

Adjustable Coagulation Capability

ABLATE (Plasma ablation & cutting): 1-9 settings adjustable;

COAG (RF& Plasma coagulation & hemostasis): 1-9 settings adjustable. This innovative "Plasma &Radio frequency" coagulation and hemostasis function can form thrombi in blood vessels to achieve thesealing effect.

03/

Smart Recognition, Simplified Design

The console can automatically identify the connections of electrode, foot switch, and power cord, and has corresponding displays and indicators on the control panel. When the electrode is properly connect-ed, the default power setting would be selected automatically. Integrated with the intelligent design, the console can precisely adjust the power value of the same setting according to different target tissues.

04/

Automatic Protection

The patented electrical circuit system can constantly monitor power output and automatically suspend power output when there is instantaneous peak current. It would automatically suspend radio frequency output when electrode contacts metal, and automatically resumes work after electrode has returned to a proper distance.

05/

Cutting and Ablation under Endoscopy

ARS Radio Frequency Plasma Surgical System has unique endoscopic cutting and ablation function. The system and electrodes have been tested according to the standards of endoscopic surgery by the health authorities, being able to safely and effectively perform foraminal endoscopic surgery.

With precise endoscopic ablation, it avoids nerve reflexes and ensures the smooth performance of intervertebral disc surgery.

06/

Temperature Control Feedback Technique

This Plasma technology provides a Controlled and Non Heat-driven process to gently dissolve target tissues at relatively low temperatures of 40-70℃. Integrated with temperature control feedback technology, the system automatically optimizes output value according to the plasma layer status around the electrode tip and the target tissue feature, by which the electrode can ensure a stable and efficient performance while keeping at the lowest working temperature.

07/

Integrated Function

In one versatile single-use electrode, it provides ABLATE for cutting, resection and ablation, COAG for coagulation and hemostasis, and suction capabilities. The integrated suction electrode enhances surgical vision, controlled resection for rapid removal of soft tissues.
